Guns loaded with value
Perf faster at a better cost per run
Yellow Jacket Oil Tools’ patent-pending PC4™ is the next generation of our popular Pre-Wired Complete gun system.
SOLID DESIGN
• Next-Generation plunging gun
contact connection on both ends of charge tube
• Addressable switch provided with
quick connect electrical connectors
• Detonator provided with quick
connect electrical connector
• Only electrical connections are two simple quick connects
• Dual ground springs provide direct ground path between addressable switch and gun body
• Charge loading tube is zinc plated to prevent corrosion and improve grounding
MORE RELIABLE
• No ports in gun string
• No wires between gun assemblies and mating subs
• Assembled in factory setting
• Compatible with Yellow Jacket’s Exclusive Plug Shoot Firing Head and Direct Connect Sub
• Premium materials with full traceability qualified through comprehensive testing protocols
• Oriented systems available
ADDITIONAL INFO
• Styles: Scalloped or Ring
• Lengths: 1’ – 30’
• Diameters: 2 3/4” ,3 1/8”, 3 3/8”
• Shots per foot: 1 – 18 SPF
• Phasing: 30°, 60°, 90°, 120°, 150°,
180°, 0°
• 20000 [138]: High pressure (psi) [MPa]
GUNS LOADED WITH VALUE
PERF FASTER AT A BETTER COST PER RUN
Yellow Jacket Oil Tools’ PC4™ is the next generation of our popular Pre- Wired Complete™ gun system.
MORE RELIABLE
• No ports in gun string
• No wires between gun assemblies and mating subs
• Assembled in factory setting
• Compatible with Yellow Jacket’s Exclusive Plug Shoot Firing Head and Direct Connect Sub
• Premium materials with full traceability qualified through comprehensive testing protocols
• Oriented systems available
SOLID DESIGN
• Next-Generation plunging gun
contact connection on both ends of charge tube
• Addressable switch provided with quick connect electrical connectors
• Detonator provided with quick connect electrical connector
• Only electrical connections are two simple quick connects
• Dual ground springs provide direct ground path between addressable switch and gun body
• Charge loading tube is zinc plated
ADDITIONAL INFO
• Styles: Scalloped or Ring
• Lengths: 1’ – 30’
• Diameters: 2 3/4” ,3 1/8”, 3 3/8”
• Shots per foot: 1 – 18 SPF
• Phasing: 30°, 60°, 90°, 120°, 150°,
180°, 0°
• 20000 [138]: High pressure (psi) [MPa]
HALO™ SELF-ORIENTING GUN SYSTEM
THE FUTURE IS UP – THE FIRST AND ONLY SELF-ORIENTING GUN SYSTEM THAT SHIPS LOADED AND ARMED.
- ENGINEERED FOR PERFECT SHOT PLACEMENT
- EQUIPPED WITH PULL & PLAY™ TECHNOLOGY
- SUPERIOR BEARING DESIGN WITH ZERO LAG
- ESG-FOCUSED DESIGN REMOVES NEARLY ALL PLASTIC
Solid design
- Next-Generation plunging gun contact connection on both ends of charge tube
- Dual ground springs provide solid ground path for addressable switch
- Compatible with any brand of switch and shaped charge
- Designed for ease of use – remove the thread protector, remove the ballistic interrupter, and install the next gun
PC3™ PERFORATING GUN
Yellow Jacket Oil Tools’ patent-pending PC3™ is the next generation of our popular Pre-Wired Complete™ gun system. Compatible with any brand of switch, shaped charge, and detonator, our customizable system reduces assembly time and risk of mis-runs.
Solid design
- Next-Generation plunging gun contact connection on both ends of charge tube
- Addressable switch installed in the end of the charge tube – wireline in, wireline out, and ground connections completed
- Only electrical connections remaining are to the detonator
- Dual ground springs provide direct ground path between addressable switch and gun body
- Compatible with any brand of switch, shaped charge, and detonator.
PULL & PLAY™ PERF GUN
Pull & Play™ guns ship loaded and armed.
The Pull & Play™ Digital Hybrid Gen-2 (DH2) Gun System is built on the legacy Pre-Wired Complete™ (PWC) Gun System with millions of runs. The beauty of this next evolution system is the ability to offer it loaded & armed, delivered straight to your shop. Yellow Jacket is the only perforating gun manufacturer with the patented technology, approved by DOT, for on-highway transportation.
Solid design
- Next-Generation plunging gun contact connection on both ends of charge tube
- Dual ground springs provide direct ground path between addressable switch and gun body
- Compatible with any brand of switch and shaped charge
- Designed for ease of use – remove the thread protector, remove the ballistic interrupter, and install the tandem sub.
